Cambium cnPilot e700 Access Point Enterprise Outdoor

Cambium Networks
Availability:

7 in stock


  • Gigabit IP67, 802.11ac wave 2, 8 dBi Outdoor Access Point
  • cnPilot e700 Enterprise Outdoor APs feature Gigabit throughput, 802.11ac Wave 2 standard with beamforming for superior outdoor Wi-Fi for enterprise campus, hospitality, higher education, and public Wi-Fi applications.

SKU: PL-E700X00A-US

KSh 73,000.00 KSh 74,000.00

7 in stock

KSh 124,000.00 for 2 item(s)

Designed for the outdoors

  • 802.11ac, 256 users, 16 SSIDs
  • Omni coverage
  • UV rated IP-67 enclosure
  • Max Operating Temp range: -40°C ~ +65°C
  • Operating humidity: 10% to 95%
  • Electrical heater for cold start
  • Ruggedized – ESD protection, Industrial grade components
  • Packaged with wall mount brackets
  • Special LTE coexistence filters
  • 315 x 215 x 66 mm | 3.174 lbs (1700 gms)

cnMaestro – WiFi Controller

  • Guest Access: Custom Splash pages, Vouchers, Social login
  • Zero-touch Provisioning
  • Inventory tracking
  • Map location
  • Monitoring: key Stats, Alarms
  • Mass (bulk) upgrade
  • Integrated troubleshooting: WiFi APs, Clients & Cambium SMs
  • Available in Cloud or as On-premises (NOC) Virtual controller

Features:

Operational superiority

IP67 weather resilient Outdoor Access Point (AP) with 512 max concurrent client associations, 16 SSIDs, WPA-2 encryption, Meshing, Dynamic VLANs, DFS channels, Access control lists (ACL), zero-touch provisioning and more – the 802.11ac wave2 powered e700 is perfect for today’s demanding high-density outdoor Wi-Fi networks.

High-performance Wi-Fi network

All cnPilot’s Enterprise Access Points (APs), support features like controllers roaming, dynamic channel selection, automatic transmit power control, band steering, and more – essential features for easy Wi-Fi operations.

Mesh

Rapidly setup multi-hop mesh networks either dedicating one radio (e.g.: 5 GHz) for mesh backhaul, or using both bands for simultaneous client and mesh access

Wireless Backhaul Integration

Roll out Wi-Fi networks rapidly with Cambium’s wireless backhaul powered from the aux PoE Out port on the e700 eliminating the need for a second power line. The aux PoE Out port can also power an 802.3af camera when security monitoring is needed near the hotspot

Resilience

Dual onboard Active/Standby memory banks ensure higher availability. The e700 can store two versions of the software and if needed fall back to working operational software, reducing the likelihood of site visits and increasing network up-time

Brands

Cambium Networks

Specifications:

cnPilot E700 Specifications
Access Point Specifications
Frequency Bands 2.4 GHz: 2.4 – 2.4835 GHz Channels 1 – 13 (ETSI/CE)
Channels 1 – 11 (US) 5 GHz: 5.15 – 5.85 GHz
SSID Security WPA-2 (802.11i): WPA2-Enterprise (802.1x/EAP) & WPA2-Preshared-keys, Open
Max SSIDs 16
Max Concurrent Clients 512
Max Data Rates 2.4GHz: 400Mbps, 5GHz: 1733Mbps
Ethernet Ports Dual Gigabit Ethernet ports (2 x 10/100/1000Base-T)
Antenna Integrated Omni
Antenna gain 8 dBi (2.4 GHz and 5 GHz)
Power Consumed Typical 18W. Max 24.6W
Dimensions 315 x 215 x 66 mm (without bracket)
Weight 3.174 lbs (1700 gms) without bracket
Wi-Fi Features
Controller modes
  • Autonomous Controller-less operations (E.g.: roaming)
  • Cloud Managed
  • On-premise virtualized controller
Secure WLAN
  • WPA-TKIP, WPA2 AES, 802.1x 802.11w (Protected Management Frames)
Hotspot 2.0/Passpoint Passpoint supported
Captive Portal
  • cnMaestro Controller
  • Stand-alone AP based
  • Redirection to external RADIUS Server
  • Server DNS logging
Authentication
  • RADIUS based 802.1x including EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, and EAP-TLS
  • MAC authentication (local database or External RADIUS server)
Scheduled SSID Turn SSID ON/OFF on a daily/weekly/time of day basis
Guest Access Yes. With Active Directory Integration

  • Vouchers
  • Rate limiting
  • Splash page creation on cnMaestro
cnMaestro Wi-Fi Controller
Common Manager Single pane of glass: Controller for Wi-Fi and network manager for ePMP and PMP wireless backhaul products
On-Boarding Secure zero-touch fast on-boarding
Provisioning Easy zero-touch virtual network provisioning Provision before install (pre-provision)
Device Inventory Inventory tracking
Trouble Shooting ezDetect: Advanced end-to-end troubleshooting of WiFi Access Point and Client devices on one single screen. Extends to Wireless backhaul (PTP), Wi-Fi Hotspot & Clients. Includes Packet capture and Wireless Analyzer functions
Configuration GUI based configuration or template-based configuration options

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “Cambium cnPilot e700 Access Point Enterprise Outdoor”

There are no reviews yet.
