Cambium cnRanger Subscriber Module (SM) 201

Cambium Networks
Availability:

6 in stock


  • 3 GHz cnRanger 201 SM, CAT6, 21 dBi (US PSU and AC Line Cord)
  • The cnRanger™ Fixed LTE wireless platform from Cambium Networks substantially increases range and coverage, while reducing the cost and complexity typically associated with LTE networks.

SKU: LTE-BBU-800

Product  Features:

  • Category 6 High Gain CPE in 3 GHz (Bands 42, 43 and 48)
  • LTE Optimized for Fixed Wireless Broadband
  • High Gain integrated parabolic dish for extended range on 201 SMs
  • Reliable yet cost-effective subscriber modules for cnRanger system
  • Easy installation, with “Point and Go” configuration and provisioning
  • LTE Optimized for Fixed Wireless Broadband
  • High Gain integrated parabolic dish for extended range
  • Reliable yet cost-effective subscriber modules for cnRanger system
  • Easy installation, with “Point and Go” configuration and provisioning
  • Surge Suppression: IEC/EN 61000-4-5, 4kV @ (1.2/50us(8/20us), 10/700us)
  • Environmental: IP67
  • Temperature -40°C to 55°C (-40°F to 131°F)
  • Humidity: 0 – 95% non-condensing
  • Wind Survival: 200 KPH (124 MPH)
  • Pole Diameter Range (w/ included mount): 38mm to 76mm (1.5 in. to 3 in.)
  • Power Consumption: 9W max
  • Input Voltage: 30 V PoE

Antenna Features
• Integrated Antenna Peak Gain: 21dBi
• 3 dB Beamwidth (Azimuth): 12°
• 3 dB Beamwidth (Elevation): 12°
• Polarization: Slant, ± 45 degrees
• Front-to-Back Isolation: >30dB
• Cross Polarization: >20dB
• Transmit Power Range (to EIRP limit by region): 66dB dynamic range
• Maximum Transit Power: 23dBm

Product Includes
(4) Cambium Networks cnRanger Subscriber Module
(4) US Power Cord
(4) High-Gain Reflector Dish
(4) Set of Mounting Hardware

SKU: 3LTE-SM-201-US Category: Tags: , ,
Brands

Cambium Networks

Specifications 3LTE-SM-201-US

LTE UE Type LTE Category 6
Spectrum
Channel Spacing 1 MHz as specified in the BBU
Frequency Range LTE Band 42: 3400-3600 MHz LTE Band 43: 3600-3800 MHz LTE Band 48: 3550-3700 MHz
Channel Width 5 MHz*, 10 MHz, 15 MHz, 20 MHz
Interface
MAC (Media Access Control) Layer TDD-LTE Advanced Release 10
Protocols Used IPv4, IPv6, UDP, TCP/IP, ICMP
Network Management HTTP, HTTPS, SSH, Cambium Networks cnMaestroTM
MTU 1516 bytes
Security
Encryption AES-128 and SNOW 3G
Authentication SIM authentication via BBU, cnMaestro or Web GUI provisions BBU with SIM information
Performance
HARQ Yes
Ultimate Sensitivity -98 dBm
Physical
Surge Suppression
Environmental IP67
Temperature / Humidity -40°C to 55°C (-40°F to 131°F), 0-95% non-condensing
Weight 3.2 kg (7 lbs)
Wind Survival 200 kph (124 mph)
Dimensions (H x W x Depth) 450 mm dia x 300 mm (17.7 in. dia x 11.8 in.)
Pole Diameter Range (w/ included mount) 38 mm to 76 mm (1.5 in to 3 in)
Power Consumption 9 W max
Input Voltage 30 V PoE
Antenna
Integrated Antenna Peak Gain 21 dBi
3 dB Beamwidth – Azimuth 12º
3 dB Beamwidth – Elevation 12º
Polarization Slant, +/- 45 Degrees
Front-To-Back Isolation > 30 dB
Cross Polarization > 20 dB
Transmit Power Range(to EIRP limit by region) 66 dB dynamic range
Maximum Transmit Power 23 dBm
Certifications
ISED Canada TBD
FCC ID Z8H89FT0060
ETSI TBD
