Ubiquiti airMAX Omni Antenna AMO-5G13

Availability:

9 in stock


  • airMAX® 2×2 Omni Antenna
  • Pair the airMAX® Omni Antenna with a Rocket™M BaseStation for 360° coverage in Point-to-MultiPoint (PtMP) networks.
  • The Ubiquiti AMO‑5G13 airMAX OmniAntenna is a Carrier Class 2×2 Dual Polarity MIMO omnidirectional antenna that was designed to seamlessly integrate with Ubiquiti Rocket M radios. (Ubiquiti Rocket M devices are sold separately)

SKU: AMO-5G13

KSh 17,800.00 KSh 18,000.00

9 in stock

KSh 36,199.00 for 3 item(s)

AirMax Omni is a Carrier Class 2×2 Dual Polarity MIMO omnidirectional antenna. Very solidly engineered, it has a built-in mounting for a Rocket M5 to clip onto and comes complete with a pair of connecting pigtails so that the two channels each connect to a separate antenna element inside the same housing for fast throughputs of up to 300 Mbps.

Simply pair a Ubiquiti Rocket M with a Ubiquiti AirMax Omni to create a powerful 360° omnidirectional base station. This seamless integration gives network architects unparalleled flexibility and convenience.

Breakthrough 2×2, Dual-Polarity Design
airMAX® Omni Antennas are the first of their kind to feature a patented, dual-polarity Omni design.

Powerful Omnidirectional Coverage
airMAX® Omni Antennas provide 360° coverage, 2×2 MIMO performance in Line-of-Sight (LOS) or Non-Line-of-Sight (NLOS) applications.

Industrial-Strength Construction
airMAX® Antennas are designed with robust mechanical design for outdoor application use.

Plug and Play Integration
Every airMAX® Antenna has a built-in Rocket™ mount, so no tools are needed to install the Rocket BaseStation.

Breakthrough 2×2, Dual-Polarity Design

airMAX® Omni Antennas are the first of their kind to feature a patented, dual-polarity Omni design.

Ubiquiti Omni Antenna AirMAX MiMo 5GHz 13dBi – Technical Specifications

General

  • Dimensions: 799 x 90 x 65 mm (31.46 x 3.54 x 2.56″)
  • Weight: 0.82 kg (1.81 lb)
  • Frequency Range: 5.45 – 5.85 GHz
  • Gain: 13 dBi
  • Elevation Beamwidth: 7°
  • Max VSWR: 1.5:1
  • Downtilt: 2°
  • Wind Survivability: 200 km/h (125 mph)
  • Wind Loading: 84.52 N @ 200 km/h (19 lbf @ 125 mph)
  • Polarisation: Dual-Linear
  • Cross-pol Isolation: 25 dB min.
  • ETSI Specification: EN 302 326 DN2
  • Mounting: Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included

* Dimensions and weight exclude pole mount and Rocket (Rocket sold separately)

Pole mounting brackets included.

Package Contents

  • 1x Omni Antenna
  • 1x Mounting Kit
  • 2x RF Pigtails

Product Features

  • 2×2 MIMO
  • 13dBi Gain
  • 1.5:1 VSWR (maximum

Check out more info about Omni Antenna AMO-2G15

SKU: AMO-5G13 Category: Tags: ,

Model Comparison

AMO-2G10
AMO-2G10
AMO-2G13
AMO-2G13
AMO-3G12
AMO-3G12
AMO-5G10
AMO-5G10
AMO-5G13
AMO-5G13
Frequency 2.4 GHz 2.4 GHz 3 GHz 5 GHz 5 GHz
Gain 10 dBi 13 dBi 12 dBi 10 dBi 13 dBi
