Ubiquiti airMAX PowerBeam M5 400mm Bridge PBE-M5-400

Availability:

8 in stock


  • High-Performance airMAX® Bridge
  • Incorporating a dish reflector design with advanced technology, the PowerBeam™ is the latest generation of Ubiquiti Networks® airMAX® CPE for customer locations.
  • The Ubiquiti airMAX PowerBeamM 5 GHz, 400mm Bridge PBE-M5-400 supports up to 150+ Mbps real TCP/IP throughput. Its Antenna Feed has a thin gray ring around the center of the cap to differentiate it from the PBE-M5-300 Antenna Feed.

SKU: PBE-M5-400

KSh 10,000.00 KSh 10,500.00

8 in stock

KSh 23,799.00 for 3 item(s)

With an all-in-one design, the Ubiquiti airMAX PowerBeam M5 PBE-M5-400 is meant to function as customer premises equipment (CPE). With a more concentrated, direct signal clients benefit from improved noise immunity as this bridge is capable of filtering out much of the noise that can degrade the signal,  Ubiquiti’s own inner feed design installation of the PBE-M5-400 has been greatly simplified as there is no longer a need for any cabling. Once installed the included airMAX technology helps network administrators to manage and monitor the network. From intelligent QoS to scalability Ubiquiti has provided the tools necessary to create long-range networks offering reliable wireless network access to a large number of clients.

The new Ubiquiti PowerBeam M5 25dBi has a compact design with uniform beam width, efficient footprint, and a faster processor. The PowerBeam can be easily mounted in a variety of ways thanks to the innovative mechanical design. The Ubiquiti PowerBeam directs RF energy into a tighter beamwidth resulting in the focus in one direction so the PowerBeam blocks or spatially filters out noise, therefore, noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.

This model of the PowerBeam features the Dish Reflector Design. This leverages Ubiquiti’s InnerFeed technology which integrates the radio into the feedhorn of the antenna, so there is no need for any cable, improving performance by eliminating cable losses. By providing increased performance with its faster processor and innovative mechanical design at a low cost, the PowerBeam is extremely versatile and cost-effective to deploy.

The Ubiquiti PowerBeam is also compatible with the RF Armor 5 GHz 12 Ubiquiti NanoBridge Ki





PowerBeam Dish Diagram

Package Contents

  • 1x Rear Housing
  • 2x Nuts
  • 1x PoE Injector
  • 1x Pole Clamp
  • 1x PBE-M5-400 Antenna Feed
  • 1x Dish Reflector
  • 1x Dish Bracket
  • 1x U-Bolt
  • 1x UK Mains cable

Product Features

  • Uniform Beamwidth Improves Noise Immunity
  • Frequency – 5 GHz
  • Throughput – 150+ Mbps
  • Range – 25+ km
  • Gain 25 dBi
  • Dish Reflector 400 mm
  • Plug and Play Installation
  • 560 MHz Processor
  • Easy Assembly and Installation

Check out more info about PowerBeam PBE-M5-400

SKU: PBE-M5-400 Category: Tags: , , , , ,

Model Comparison

PBE-M2-400
PBE-M5-300
PBE-M5-400
PBE-M5-620
Frequency 2 GHz 5 GHz 5 GHz 5 GHz
Throughput 150+ Mbps 150+ Mbps 150+ Mbps 150+ Mbps
Range 20+ km 20+ km 25+ km 30+ km
