Ubiquiti airMAX Sector 2.4GHz 15dBi AM-2G15-120

Availability:

9 in stock


  • airMAX® 2×2 BaseStation Sector Antenna
  • Pair the airMAX® Sector Antenna with a Rocket™M BaseStation for sector coverage in Point-to-MultiPoint (PtMP) networks.
  • The AM-2G15-120 AirMAX 2.4 GHz 2×2 MIMO Sector Antenna from Ubiquiti Networks provides networking flexibility and convenience by letting you create a customized base station with an optional RocketM radio. The Ubiquiti AMO-2G15-120 2.4GHz 15dBi airMAX Sector operates under the 2.4 GHz frequency and offers a gain of 15 dBi. The Ubiquiti AirMAX Sector Antenna delivers 2×2 MIMO performance and supports airMAX technology, which uses a Time Division Multiple Access protocols to send and receive data at pre-designated time slots. Included along with the antenna are a pole mount, RocketM bracket, and weatherproof RF jumpers to make your base station building experience easier.

SKU: AM-2G15-120

KSh 27,499.00 KSh 28,000.00

9 in stock

KSh 51,897.00 for 3 item(s)

Product Details

Dual polarity 2.4 GHz antenna for use with Ubiquiti Rockets which clip into the back making for quick and easy deployment.

Includes two SMA RP jack sockets for radio connections.

Rocket mating bracket provides solid mounting for Rocket M2.

The antenna is supplied with two pigtails to connect a Rocket M2.

See manufacturer’s spec sheet for polar response diagrams.

Breakthrough Design and Performance

The innovative airMAX® Sector Antennas feature carrier-class construction and 2×2, dual-polarity performance.

Package Contents

  • 1x Mounting Kit
  • 2x RF Pigtails
  • 1x Sector Antenna

Ubiquiti AM-2G15-120 Key Product Features

  • Wind loading: 160 mph
  • Frequency Range: 2.3-2.7GHz
  • Gain: 15.0 – 16.0dBi
  • Polarisation: Dual Linear
  • Cross-pol Isolation: 28 db Min
  • 15dBi Gain
  • Dual Linear Polarisation
  • 2x SMA RP jack sockets



Check out more info about  Sector Antenna AM-2G15-120

Model Comparison

AM-9M13
AM-9M13
AM-2G15-120
AM-2G15-120
AM-2G16-90
AM-2G16-90
AM-V2G-Ti
AM-V2G-Ti
AM-3G18-120
AM-3G18-120
Frequency 900 MHz 2.4 GHz 2.4 GHz 2.4 GHz 3 GHz
Gain 13 dBi 15 dBi 16 dBi 60°: 17 dBi
90°: 16 dBi
120°: 15 dBi
18 dBi
AM-5G16-120
AM-5G16-120
AM-5G17-90
AM-5G17-90
AM-M-V5G-Ti
AM-M-V5G-Ti
AM-5G19-120
AM-5G19-120
AM-5G20-90
AM-5G20-90
Frequency 5 GHz 5 GHz 5 GHz 5 GHz 5 GHz
Gain 16 dBi 17 dBi 60°: 17 dBi
90°: 16 dBi
120°: 15 dBi
19 dBi 20 dBi
AM-V5G-Ti
AM-V5G-Ti
Frequency 5 GHz
Gain 60°: 21 dBi
90°: 20 dBi
120°: 19 dBi
