Module
Name
TAT140-QJIBO: Questel EG915U-EU with Teltonika TM2500;
TAT140-QKIB0: Quectel EG915U-LA with Teltonika TM2500

Technology: LTE Cat 1/GSM/GPRS/GNSS/BLUETOOTH

GNSS
GNSS: GPS, GLONASS, GALILEO, BEIDOU
Receiver: 33 channel
Tracking sensitivity: -165 dBM
Accuracy: < 2.5 m CEP

Cellular
Technology: LTE Cat 1, GSM
2G bands:
TAT140-QJIBO: EG915U-EU GSM: B2/B3/B5/B8;
TAT140-QKIB0: EG915U-LA GSM: B2/B3/B5/B8
4G LTE Cat 1 bands:
TAT140-QJIBO: EG915U-EU LTE-FDD: B1/B3/B5/B7/B8/B20/B28;
TAT140-QKIB0: EG915U-LA LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66
Data transfer
LTE: LTE FDD : Max 10Mbps (DL)/Max 5Mbps (UL)
GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support: SMS (text/data)

Power
Internal battery: Extremely low self-discharge Li-SOCl2 swappable battery, 7,2V 2200mAh

Bluetooth
Specification:4.2 + LE
Supported peripherals: ELA sensors, EYE sensors, Beacons, Universal BLE sensor support

Physical specification
Dimensions: 78 x 63 x 28 mm (L x W x H)
Weight: 115g (when 2 cell batteries are used)

Interface
GNSS antenna: Internal High Gain
Cellular antenna: Internal GSM High Gain
USB: 2.0 Micro-USB
LED indication: 1 status LED light
SIM: Micro-SIM
Memory: 128MB internal flash memory

Operating environment
Operating temperature (without battery): -20 °C to +60 °C
Battery discharge temperature: -60 °C to +85 °C
Battery storage temperature: Recommended max 30°C
Ingress Protection Rating: IP68

Features
Scenarios: Accelerometer wake up, GNSS, Bluetooth sensor support, Recovery mode, Periodic tracking on stop / on move, Scheduler with time zones, Backup tracking, Static navigation, Lost BLE sensor
Sensors: Accelerometer
Sleep modes: Single custom sleep mode
Configuration and firmware update: FOTA Web, Teltonika Configurator (USB)
SMS: Configuration, Events, Debug
GPRS commands: Configuration, Debug
Time Synchronization: GNSS, NITZ, NTP

Certification & approvals
Regulatory: CE/RED, E-Mark, RCM, UKCA – pending
