MikroTik LoRa wAP LR8 kit RBwAPR-2nD&R11e-LR8

MikroTik Wireless
Availability:

7 in stock


  • An out-of-the-box gateway solution for LoRa® technology, 863-870 MHz
  • wAP LR8 kit – an out-of-the-box solution to use LoRa® technology. This kit contains a pre-installed UDP packet forwarder to any public or private LoRa® servers and an outdoor weatherproof wireless access point with 2.4 GHz WLAN interface and Ethernet port that could be used as a backend.
  • This particular wAP form-factor has been tested in many other MikroTik products – it can deliver excellent and stable performance in almost any weather condition.
  • You can use the optional internal 2 dBi antenna or attach an external antenna. For extra network coverage, we suggest adding the MikroTik Antenna kit for LoRa®.wAP LR8 kit supports 863-870 MHz frequency, used in European Union, Russia, India etc.Functional and non-intrusive design, astonishing durability, and great value – that is the wAP LR8 kit, the long-awaited solution for LoRa® technology for enthusiasts of any level.



SKU: RBwAPR-2nD&R11e-LR8



KSh 15,000.00

7 in stock

KSh 28,999.00 for 3 item(s)

wAP LR8 kit – an out-of-the-box solution to use LoRa® technology. This kit contains a pre-installed UDP packet forwarder to any public or private LoRa® servers and an outdoor weatherproof wireless access point with 2.4 GHz WLAN interface and Ethernet port that could be used as a backend.

This particular wAP form-factor has been tested in many other MikroTik products – it can deliver excellent and stable performance in almost any weather condition.

You can use the optional internal 2 dBi antenna or attach an external antenna. For extra network coverage, we suggest adding the MikroTik Antenna kit for LoRa®.

wAP LR8 kit supports 863-870 MHz frequency, used in European Union, Russia, India etc.

Functional and non-intrusive design, astonishing durability, and great value – that is the wAP LR8 kit, the long-awaited solution for LoRa® technology for enthusiasts of any level.

Included parts

SKU: RBwAPR-2nD&R11e-LR8 Categories: , Tags: , , ,
Brands

MikroTik Wireless

Specifications

Details
Product code RBwAPR-2nD&R11e-LR8
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
RouterOS license 4
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 100’000 hours at 25C
Tested ambient temperature -40°C to 60°C
Suggested price $169.00

Powering

Details
Number of DC inputs 3 (DC jack, PoE-IN, Automotive)
DC jack input Voltage 9-30 V
Automotive input Voltage 9-30 V
Max power consumption 7 W
FAN count Passive
PoE in Passive PoE
PoE in input Voltage 9-30 V

Wireless specifications

Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 2
Wireless 2.4 GHz chip model QCA9531
Wireless 2.4 GHz generation Wi-Fi 4

Ethernet

Details
10/100 Ethernet ports 1

Peripherals

Details
Number of SIM slots 1 Modem (Mini SIM)
MiniPCI-e slots 1

Other

Details
PCB temperature monitor Yes
Voltage Monitor Yes

Certification & Approvals

Details
Certification CE, FCC, IC, EAC, ROHS
IP 54

Wireless specifications

2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 22 -96
11MBit/s 22 -89
6MBit/s 20 -93
54MBit/s 18 -74
MCS0 20 -93
MCS7 16 -71
